DC solar · JIABO Practical Series
JBSD and JBYR DC Solar Submersible Pumps
Submersible solar pumps for drainage and high-volume, low-head water movement.
Power280-2,200 W
Maximum flow5-56 m³/h
Maximum head7-30 m
Outlet1-4"
Applications
Where this family fits.
- Site drainage
- Pond transfer
- Agricultural dewatering
Construction
Catalog-specified materials.
- Iron outlet and pump head
- Iron or aluminium body by family
- Aluminium impeller
- 2 m cable
Representative selection
Example models.
Values shown are catalog maximums, not a guaranteed operating point. Use the performance curve and system calculation for final selection.
| Model | Power | Max flow | Max head | Outlet |
|---|---|---|---|---|
| JBSD5.0/15-30/280-1 | 280 W | 5.0 m³/h | 15 m | 1" |
| JBSD17.0/30-72/1300-2 | 1,300 W | 17.0 m³/h | 30 m | 2" |
| JBYR40-10-144-1100 | 1,100 W | 40 m³/h | 10 m | 3" |
| JBYR56-14-280-2200 | 2,200 W | 56 m³/h | 14 m | 4" |
Avoid undersizing
Let us match the pump to your system.
Include flow, total dynamic head, well diameter, water level, pipe length, location and power source.
